API 602 Forged Globe Valve, 1 Inch, Class 2500 LB, Welded Bonnet, ASTM A182 F91 Body, NPT End.
Valve Description:
1852052 Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Welded Bonnet, Bonnetless, Bolted Bonnet, Pressure Seal Bonnet,
Nominal Size: 1 Inch, DN25
Nominal Class: CL 2500 LB
Bore Type: Reduced
Face to Face: MFG'S
Operation: Handwheel
Body Material: ASTM A182 F91, ASTM A182 F22, ASTM A182 F11, ASTM A105N, ASTM A182 F316
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
Applications: Chemical Processing, Water Treatment Plants, Oil and Gas Industry.
End Connection: NPT(National Pipe Thread), BW(Butt Weld), SW(Socket Weld)
Applications: Chemical Processing, Oil and Gas Industry, Water Treatment Plants.
Key Features:
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Benefits
1. Reduced Pressure Drop: The angled flow path minimizes the resistance to flow and reduces pressure drop, making it more efficient for fluid handling.
2. Improved Flow Control: Provides accurate control of fluid flow and is suitable for regulating the flow in high-pressure and high-temperature applications.
3. Less Turbulence: The design helps in reducing turbulence, which can improve the overall efficiency and performance of the system.
| Product Portfolio |
| Normal Diameter: |
1/2-2 Inch (DN15-DN50) |
| Pressure Range: |
800-4500 LB |
| Body Material: |
Carbon Steel, Stainless Steel, Alloy Steel |
| Operation: |
Manual or Actuated |
| End Connection: |
BW/SW/NPT |
| Working Temperature: |
-29°C to +525°C |
