Wafer Type Butterfly Valve, API 609, Titanium, CL150, 36 IN

Key Specifications / Features

Model no. : 1862176

As a trusted supplier of API 609 Category B butterfly valves, we offer high-quality solutions designed to meet EN 593 standards. Our 36-inch titanium butterfly valves feature a double offset design, ensuring reliable performance and durability. Equipped with a 17-4PH stainless steel stem and a soft RPTFE seat, these Class 150 LB valves provide excellent sealing and corrosion resistance. With wafer end connections, our butterfly valves are ideal for demanding applications across various industries, offering smooth operation and long-lasting performance.

Detail Information

API 609 High-Performance Butterfly Valve, Double Offset, 36 Inch, CL 150 LB, RPTFE Seat.

Valve Description

1862176 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 36 Inch, DN900
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Operation: Gear
Body Material: Titanium, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium.
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: CL 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
