Key Specifications / Features

Model no. : 2SBS1WWCB

Get top-quality Viton seat dual plate check valve, featuring 2 inches size, 150 LB pressure rating, ASTM A216 WCB body, API 594 compliance, DN50 size, PN20 pressure rating, ASTM A351 CF8M disc, X-750 spring, and wafer-RF end. Perfect for various industrial applications.


Detail Information

2-inch Viton Seat Dual Plate Check Valve, API 594, 150 LB, WCB Body, CF8M Disc

Valve Description:
1842015 Dual Plate Check Valve 2SBS1WWCB
Design Standard: API 594
Structure: Dual Plate spring return
Nominal size: 2 Inch
Nominal class: 150 LB
End Connection: Wafer-RF
Operation: /
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, X-750 Spring, Viton seat
Face to face: API 594
Test and inspection: API 598
Key Features: Retainerless Design, HIgh flow efficiency, Low noise, Short face-to-face length

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: Wafer, Lug, Flanged, HUB
Working temperature: -46℃ - +200℃
Operation: /
