Trunnion Ball Valves, API 6D, A350 LF2, 42 IN, CL1500, DBB

Key Specifications / Features

Model no. : 1811174

We offer high-performance ball valves that adhere to API 6D standards. Our 42-inch (DN1050) ball valves feature a 3-piece bolted body and are rated for Class 1500 LB pressure. With soft seats for dependable sealing and a Double Block & Bleed (DBB) feature for added safety, these valves also come with RTJ flanged ends for secure, leak-proof connections. Engineered for exceptional durability and performance, they are ideal for high-pressure and critical applications. As a leading ball valve manufacturer in China, we are committed to delivering top-quality solutions for demanding industrial needs.

Detail Information

Trunnion Mounted Ball Valve, API 6D, BS 5351, 42 Inch/DN1050, 3pcs Bolted Body, RTJ.

Valve Description

1811174 Trunnion Mounted Ball Valve
Design Standard: API 6D, BS 5351
Nominal Size: 42 Inch, DN1050
Nominal Class: CL 1500 LB, PN250
Body Material: Carbon Steel ASTM A105N or ASTM A350 LF2
Bore Type: Full Bore or Reduced Bore
Operation: Lever/Gear
Test and inspection: API 598, API 6D
Structure: 3pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to Face: ASME B16.10
End Connection: RTJ Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55, ASTM A105+ENP, ASTM A350 LF2+ENP
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire-Safe Design, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission (Optional), DIB (Optional).

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: 150 - 2500 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C to +150°C
End Connection: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW), Hub
Body Types: 2pc split body, 3pcs split body
Body&Bonnet Connection: Bolted Bonnet, Full Welded Bonnet(for Hazardous service need longer working life with less leakage point)
