Our company is widely recognized as one of the most reliable triple-offset butterfly valve manufacturers in China.
Design Standards: API 609 Cat B
Size Range: 2 - 72 Inch
Pressure Range: Class 150-2500 LB
End Connections: Wafer, Lug, Flanged (FF, RF, RTJ), BW
Material Types: Carbon Steel, Stainless Steel, Duplex Steel, Al-BRZ, Alloy, Ti
Seat Type: Metal with Hard facing
Disc Seat:
Solid metal seal ring (for bi-direction service)
or laminated graphite+SS seal ring
or laminated PTFE+SS seal ring (for service need cleanness like seawater)
Top Mounting: ISO 5211 top mounting is available
Operation Types: Lever, Gear, Pneumatic Actuator, Motor Actuator
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and fire safe
Design Standards: API 609 Cat B
Size Range: 2 - 72 Inch
Pressure Range: Class 150-2500 LB
End Connections: Wafer, Lug, Flanged (FF, RF, RTJ), BW
Material Types: Carbon Steel, Stainless Steel, Duplex Steel, Al-BRZ, Alloy, Ti
Seat Type: Metal with Hard facing
Disc Seat:
Solid metal seal ring (for bi-direction service)
or laminated graphite+SS seal ring
or laminated PTFE+SS seal ring (for service need cleanness like seawater)
Top Mounting: ISO 5211 top mounting is available
Operation Types: Lever, Gear, Pneumatic Actuator, Motor Actuator
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and fire safe
Showing 1–12 of 8 results
Top QUALITY Triple Offset Butterfly ValveS FOR YOU
A triple offset butterfly valve (TOV, HPBV or TOBV) is widely used in critical applications for isolation and regulating services.
If you need any support about our Butterfly Valves, pls contact us!
Request a quote
If you need any support about our Butterfly Valves, pls contact us!
TRIPLE OFFSET BUTTERFLY VALVE
Compared with double offset butterfly valves, the design of A triple offset butterfly valve is similar but with a metal seat and an additional 3rd offset (disc-seat contact axis), which makes it with better sealing and less wear, and it's able to work under low/high temperature, higher pressure and various fluid.
Main Features:
Offset Design
3rd offset: the disc seat contact axis is offset from the pipe axis, minimizing the contact of seats and having better sealing performance.
Compact Design and Low Emission and anti-blowout stem design
ISO 5211 Top Mounting
Different End Connections Available:
Dead End Service
When the valves need to be installed at end of the pipe and one side has no connection with the ant pipe/flange, the valve needs a special design like threaded holes and bi-direction sealing.
Inherent Fire Safe
The disc seat is solid/laminated metal and the body seat is also metal hard-faced with CoCr alloy which is all fire-safe materials.
CV Value
Flow parameters
Compared with double offset butterfly valves, the design of A triple offset butterfly valve is similar but with a metal seat and an additional 3rd offset (disc-seat contact axis), which makes it with better sealing and less wear, and it's able to work under low/high temperature, higher pressure and various fluid.
Main Features:
Offset Design
3rd offset: the disc seat contact axis is offset from the pipe axis, minimizing the contact of seats and having better sealing performance.
Compact Design and Low Emission and anti-blowout stem design
ISO 5211 Top Mounting
Different End Connections Available:
Dead End Service
When the valves need to be installed at end of the pipe and one side has no connection with the ant pipe/flange, the valve needs a special design like threaded holes and bi-direction sealing.
Inherent Fire Safe
The disc seat is solid/laminated metal and the body seat is also metal hard-faced with CoCr alloy which is all fire-safe materials.
CV Value
Flow parameters
