Stainless Steel Gate Valve, F316, API 602, 3/4 Inch, 800 LB

Key Specifications / Features

Model no. : 0.75G8SF31612

This F316 Stainless Steel Forged Gate Valve complies with API 602 standards and features a 3/4 inch size and 800 lb pressure rating with socket weld ends. It has an A182 F316 body and Trim 12, and is operated with a handwheel.

Request a quote

Tags:

3/4 Inch Gate Valve

Class 800 LB Gate Valve

ASTM A182 F316 Gate Valve

Detail Information

F316 Stainless Steel Forged Gate Valve, API 602, 3/4 INCH, 800 LB, SW, A182 F316 Body, Trim 12, Handwheel

Valve Description:
1851011 API 602 Forged Gate Valve 0.75G8SF31612
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 3/4 Inch
Nominal class: Class 800 LB
Bore: Regular Bore
End Connection: SW-Socket Weld End
Operation: Handwheel
Body Material: ASTM A182 F316
Trim Material: SS316+STL, No.12
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
