Stainless Steel Dual Plate Check Valve, 42 IN, 150 LB, CF8M

Key Specifications / Features

Model no. : 1842037

As a prominent fabricator of 42-inch dual plate check valves in China, we specialize in high-quality valves made from stainless steel ASTM A351 CF8M. Our valves, with a DN1050 size and Class 150 LB rating, are designed to meet API 594 and API 6D standards. Featuring wafer lug ends and a compact, slim plate design, these valves offer both efficiency and space-saving benefits. The spring-loaded mechanism ensures reliable operation with rapid closure, while the independent spring system enhances performance by reducing the risk of valve binding. Our valves come with optional soft and metal seats, providing flexibility for various applications. Ideal for use in demanding environments, such as water and wastewater treatment or industrial processes, these valves deliver durability and dependable performance. Trust our expertise for valves that combine superior engineering with advanced functionality.


Detail Information

Stainless Steel Dual Plate Check Valve, ASTM A351 CF8M, 42 Inch/DN1050, Class 150 LB, API 594, Wafer, Lug Ends.

Valve Description:

1842037 Dual Plate Check Valve
Design Standard: API 594, API 6D
Structure: Spring Loaded, Dual Plate
Key Features: Compact Design, Independent Spring, Optional Soft and Metal Seat, Unique Slim Plate Design.
Nominal Size: 42 Inch, DN1050
Nominal Class: ANSI Class 150
Body Material: ASTM A351 CF8M, ASTM B148 C95800, ASTM A890 5A, ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A890 4A, Titanium Alloy.
Bore Type: /
End Connection: Wafer, Lug, Double Flanged
Operation: /
Trim Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium Alloy.
Face to Face: API 594
Test and Inspection: API 598


Product Selection:

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2-48 Inch (DN15 - DN1200)
Pressure Range: Class 150-2500 LB
Working Temperature: -196°C - +450°C
Seat Type: Soft Seat, Metal Seat
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Wafer, Lug, Flanged(FF, RF, RTJ), Butt Weld(BW), HUB


The Dual Plate Check Valve is a spring-loaded, non-return valve designed to prevent backflow in pipelines. As a one-way valve, it ensures that fluid flows in the desired direction while blocking any return flow. This valve features a one-piece body with a centrally located pin, which secures two plates loaded with springs. When fluid flows in the correct direction, the plates open to allow passage. In the event of reverse flow, the plates close to prevent backflow.

Compared to conventional swing check valves, the dual plate design significantly reduces both weight and length, resulting in cost and space savings for the piping system. This makes it an efficient and economical choice for various industrial applications.

Dual Plate Check valve
