Spring Loaded Dual Plate Check Valve, 14 IN, 150 LB, A216 WCB

Key Specifications / Features

Model no. : 1842026

Our 14-inch Dual Plate Check Valve, made from ASTM A216 WCB carbon steel, is engineered to meet API 6D and API 594 standards. Rated for 150 LB, this valve features flanged ends for easy installation. The innovative slim plate design ensures reduced weight and improved flow efficiency. It offers low pressure loss, quick operation, and excellent sealing performance, even at low pressures. Designed for reliability and effectiveness, this valve is a top choice for diverse industrial applications.

Detail Information

Spring Loaded Dual Plate Check Valve, API 6D, 14 Inch, 150 LB, ASTM A216 WCB Body, Flanged End.


Check Valve Description:
1842026 Dual Plate Check Valve
Design Standard: API 6D, API 594
Structure: Spring Loaded, Dual Plate
Nominal Size: 14 Inch
Nominal Class: Class 150 LB
Body Material: ASTM A216 WCB, Titanium Alloy, ASTM B148 C95800, ASTM A890 5A, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A.
Bore Type: /
End Connection: Wafer, Lug, Double Flanged
Operation: /
Trim Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium Alloy.
Face to Face: API 594
Test and Inspection: API 598
Key Features: Compact Design, Independent Spring, Optional Soft and Metal Seat, Unique Slim Plate Design.


Product Portfolio:

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
Seat Type: Soft Seat, Metal Seat
End Connections: Wafer, Lug, Flanged(FF, RF, RTJ), Butt Weld(BW), HUB
