Pressure Seal Bonnet Gate Valve, A352 LCB, 2-1/2 IN, CL900

Key Specifications / Features

Model no. : 1821107

We are an ASTM A352 LCB wedge gate valves leading manufacturer in China, engineered for high performance and durability. Our 2-1/2-inch (DN65) valves are constructed from carbon steel ASTM A352 LCB and are rated at Class 900 LB. Featuring an OS&Y configuration and RTJ flanged connections, these valves ensure secure, leak-proof sealing. The rising stem design allows for smooth operation and precise control. Ideal for demanding industrial applications, our gate valves provide reliable performance and long-lasting service in high-pressure environments.

Detail Information

API 600 Gate Valve, OS&Y, ASTM A352 LCB, 2-1/2 Inch, DN65, Class 900 LB, RTJ Flanged.

Valve Description

1821107 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, ASTM A216 WCB, ASTM A890 4A, ASTM A890 5A.
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: 900 LB, PN150
Face to Face: ASME B16.10
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Test and Inspection: API 598
End Connection: RTJ Flanged

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
Material Types: Steel Gate Valve(cast and forged), Iron Gate Valve
Seat Types: Metal Seat Gate Valve(hard faced), Resilient Gate Valve(rubber seat) Bonnet
