Pneumatic Actuated Ball Valve, ASTM A351 CF8, 2 IN, 1000 WOG

Key Specifications / Features

Model no. : 2B1000SCF8

Discover our high-quality 1000 WOG pneumatic actuated Floating Ball Valve, designed to meet API 608 standards. This valve features a DN50 size, available in both SW/NPT connection options. Crafted with an A351 CF8 Body and equipped with F304 Trim, it ensures durability and reliable performance. The Soft Seat adds to its efficiency, while the ISO 5211 Mounting pad simplifies installation. Experience excellence in valve technology with this precision-engineered solution.


Detail Information

1000 WOG pneumatic actuated Floating Ball Valve, API 608, DN50, SW/NPT, A351 CF8 Body, F304 Trim, Soft Seat, ISO 5211 Mounting pad

Valve Description:
1812017 Floating Ball Valve 2B1000SCF8
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 2 Inch, DN50
Nominal class: 1000 WOG
Bore Type: Full Bore
End Connection: SW
Operation: pneumatic actuator
Body Material: ASTM A351 CF8
Trim Material: ASTM A182 F304, RPTFE/TFM 1600
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Stainless Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: Class 150 - 300LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
