Monel K500 Stem Butterfly Valve, CL 300, 36 Inch, A216 WCB

Key Specifications / Features

Model no. : 1862323

As a leading manufacturer of EN 593 butterfly valves, we produce high-performance solutions meeting API 609 Category B standards. Our 36-inch valves feature a double offset design with a robust A216 WCB body and an RPTFE seat for reliable sealing. Equipped with a Monel K500 stem and rated at Class 300 LB, these valves ensure durability and superior performance in demanding applications. The wafer ends facilitate easy installation, making them ideal for precise control and regulation in industrial systems.

Detail Information

API 609 Butterfly Valve, ASTM A216 WCB Body, 36 Inch, 300 LB, RPTFE Seated.

Valve Description

1862323 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A216 WCB, Titanium, ASTM A890 5A, ASTM A351 CF8M, ASTM B148 C95800, ASTM A351 CF8, ASTM A890 4A.
Nominal Size: 36 Inch
Nominal Class: Class 300 LB, PN50
Structure: Double Offset, Double Eccentric
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Wafer
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: Class 150 - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe Design.
