High-Performance Butterfly Valve, CF8M, API 609, 2 IN, CL150

Key Specifications / Features

Model no. : 1862117

We manufacture high-quality double-flanged butterfly valves that comply with EN 593 and API 609 Category B standards. Our 2-inch (DN50), 150 LB valves feature a double eccentric design and are constructed from CF8M stainless steel, offering superior durability and corrosion resistance. With a 17-4PH stem and RPTFE seat, these valves ensure reliable sealing and smooth operation across a variety of industrial applications. Engineered for long-term performance, our valves provide a dependable solution for even the most demanding environments. As a leading butterfly valve manufacturer in China, we are committed to delivering excellence in every product.

Detail Information

API 609 Butterfly Valve, EN 593, Double Eccentric, 2 Inch/DN50, 150 LB, Double Flanged End.

Valve Description

1862117 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 2 Inch, DN50
Nominal Class: Class 150 LB, PN20
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A351 CF8M, ASTM A351 CF8, ASTM A216 WCB, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.
Seat: RPTFE, PPL
End Connection: Double Flanged
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
