High-Performance Butterfly Valve, CF8, API 609, 2 IN, CL300

Key Specifications / Features

Model no. : 1862096

We manufacture ASTM A351 CF8 butterfly valves designed to EN 593 and API 609 Category B standards. Our double eccentric valves are available in a 2-inch size (DN50) with a 150 LB pressure rating, offering excellent durability and performance. Equipped with a 17-4PH stainless steel stem and an RPTFE seat, these valves provide reliable sealing and corrosion resistance. The lug end connection ensures secure installation, making them ideal for various industrial applications. These valves deliver precise control and long-lasting operation in demanding environments. As a leading butterfly valve manufacturer in China, we are committed to providing high-quality solutions.

Detail Information

API 609 Butterfly Valve, EN 593, Double Eccentric, 2 Inch/DN50, 300 LB, Lug End.

Valve Description

1862096 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentri
Nominal Size: 2 Inch, DN50
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A216 WCB, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.
Seat: RPTFE, PPL
End Connection: Lug
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
