GGG40 Butterfly Valve, 72 Inch, PN10, EN 593, DN1800

Key Specifications / Features

Looking for a reliable supplier of soft seat triple offset butterfly valves? Our company offers a comprehensive range of high-quality valves to meet your industrial needs. With a size of 72 inches (DN1800) and a pressure rating of PN10, our valves adhere to the EN 593 and Class 150 LB standards. Designed with double flanges and crafted from durable ductile iron GGG40 material, our valves ensure optimal performance and longevity. The GGG40 disc and EPDM O-ring provide excellent sealing capabilities, making our valves suitable for various applications. Trust us as your go-to supplier for top-notch butterfly valves.

Request a quote

Tags:

PN10 Butterfly Valve

EN 593 Butterfly Valve

Ductile Iron Butterfly Valve

Detail Information

72 inch (DN1800) Soft Seat Triple Offset Butterfly Valve, EN 593, PN10, Double Flange, Ductile iron GGG40 body, GGG40 Disc, EPDM O-ring

Valve Description:
1863004 Triple Offset Butterfly Valve 72TC1RDI
Design Standard: EN 593
Structure: Triple Offset
Nominal size: 72 Inch
Nominal class: PN10
End Connection: Double Flange, EN 1092
Operation: Gear
Body Material: GGG40
Trim Material: A351 CF8M disc, Laminated Sealing ring SS316+Graphite
Face to face: API 609
Test and inspection: API 598
Key Features: Low torque, Zero Leakage, Excellent control characteristics

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: Class 150 - 2500 LB
End connection: Wafer, Lug, Flanged, BW
Working temperature: -29℃ - +400℃
Operation: Lever, Gear, Motor, Pneumatic Actuated
