Key Specifications / Features
Our Full Opening Swing Check Valve is expertly fabricated in China, designed for robust performance in industrial applications. Constructed from durable ASTM A216 WCB carbon steel, this valve ensures reliable operation and longevity. Featuring Trim 8 and complying with BS 1868 and API 594 standards, it is suitable for Class 300 LB environments. Sized at 8 inches, with RF flanged ends for easy installation and maintenance, this valve offers efficient fluid flow control. Ideal for various industrial uses, our Full Opening Swing Check Valve provides dependable performance and durability. Choose our product for its quality craftsmanship and suitability for demanding operational conditions.
Detail Information
API 6D Swing Check Valve, 8 Inch, Class 300 LB, Full Opening, Carbon Steel, A216 WCB Body With Trim 8.
Valve Description
1841046 Swing Check Valve
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available
Design Standard: API 6D, BS 1868, API 594
Body Material: ASTM A216 WCB, Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A352 LCB, ASTM A995 4A, 5A.
Structure: Bolted Bonnet
Nominal Size: 8 Inch
Nominal Class: 300 LB
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: Flanged RF
Operation: Lever
Product Offering
Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-bronze
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: 150-2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
Working temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
