Key Specifications / Features
The API 6D Swing Check Valve, is designed for robust performance and reliability. This valve features a 6-inch size and 600 LB class, with a full opening design for optimal flow efficiency. Crafted from durable carbon steel (A216 WCB) and equipped with Trim 8, it ensures dependable operation in demanding environments. Ideal for industrial applications requiring secure, leak-free performance with precise control over flow dynamics.
Detail Information
API 6D Swing Check Valve, 6 Inch, Class 600 LB, Full Opening, Carbon Steel, ASTM A216 WCB, Trim 8.
Valve Description
1841066 Swing Check Valve
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Gear Design Available
Design Standard: API 6D, BS 1868, API 594
Body Material: ASTM A216 WCB, Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A352 LCB, ASTM A995 4A, 5A.
Nominal Size: 6 Inch
Nominal Class: 600 LB
Structure: Bolted Bonnet
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: Flanged RF
Operation: Gear
Product Offering
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: Class 150-2500 LB
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Aluminium-Bronze
Operation: Not Applicable
Working temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
