Flexible Wedge Gate Valve, 24 IN, CL150, ASTM B148 C95800

Key Specifications / Features

Model no. : 1821055

As a trusted gate valve manufacturer in China, we specialize in producing high-quality ASTM B148 C95800 aluminum bronze valves. Built to meet API 600 standards, our 24-inch (DN600) gate valves feature an OS&Y design for reliable operation and are rated ANSI 150 for optimal pressure handling. The valves come with a pressure seal bonnet, ensuring exceptional sealing in high-pressure environments, and are equipped with RF flanged connections for secure installation. Our durable aluminum bronze construction offers superior corrosion resistance, making these valves ideal for demanding industrial applications.

Detail Information

OS&Y Gate Valve, 24 Inch, ASTM B148 C95800, API 600, DN600, Class 150 LB, Flexible Wedge, RF Flanged.

Valve Description

1821055 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8M, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800.
Nominal Size: 24 Inch, DN600
Nominal Class: CL 150 LB, PN10, PN16
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
End Connection: RF Flanged
Face to Face: ASME B16.10
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
