EN 593 Wafer Type Butterfly Valve, A351 CF8M, CL300, 32 IN

Key Specifications / Features

Model no. : 1862196

We supply high-quality butterfly valves designed to meet API 609 Category B and EN 593 standards. Our double offset valves are made from durable A351 CF8M stainless steel, providing excellent corrosion resistance. With a 32-inch size and Class 300 LB rating, these valves are equipped with a 17-4PH stem for enhanced strength and durability. The soft RPTFE seat ensures tight sealing and reliable performance. Featuring wafer ends for easy installation, these valves are ideal for a wide range of industrial applications. Trust us as your reliable supplier of premium butterfly valves.

Detail Information

API 609 High-Performance Butterfly Valve, Double Offset, 32 Inch, CL 300 LB, RPTFE Seat.

Valve Description

1862196 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 32 Inch, DN800
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, ASTM A890 4A, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium.
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: CL 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
