EN 593 Titanium Butterfly Valve, API 609, 4 IN, 150 LBS

Key Specifications / Features

Model no. : 1862162

As a leading provider of API 609 butterfly valves in China, we offer high-performance solutions crafted from durable titanium. Our 4-inch (DN100) double eccentric valves meet EN 593 standards, ensuring reliable operation in demanding environments. Rated at Class 150 LB, these valves feature a 17-4PH stem for superior strength and corrosion resistance, along with an RPTFE seat for excellent sealing. The wafer end design allows for easy installation across a variety of industrial applications. Our valves are engineered for long-lasting performance and precision.

Detail Information

Double Eccentric Butterfly Valve, 4 Inch/DN100, 150 LB, Titanium Body, Lever Operation.

Valve Description

1862162 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8, ASTM B148 C95800, ASTM A890 4A, ASTM A351 CF8M.
Nominal Size: 4 Inch, DN100
Structure: Double Offset, Double Eccentric
Nominal Class: Class 150 LBS, PN20
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Lever
Seat: RPTFE, PPL
End Connection: Wafer
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
