EN 593 Soft Seated Butterfly Valve, A890 4A, CL 150, 30 IN

Key Specifications / Features

Model no. : 1862216

As a trusted supplier of API 609 Category B butterfly valves, we provide high-quality valves designed to meet EN 593 standards. Featuring a double offset design, these valves are crafted from A890 4A material with a 30-inch size and Class 150 LB rating. Equipped with a 17-4PH stem, soft RPTFE seat, and lug ends, they ensure reliable performance. Bosseal valve advantages include zero leakage, low torque, extended working life, low emissions, bi-directional flow, and fire-safe capabilities, making them ideal for demanding applications.

Detail Information

API 609 High-Performance Butterfly Valve, Double Offset, 30 Inch, CL 150 LB, RPTFE Seat.

Valve Description

1862216 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 30 Inch, DN750
Nominal Class: Class 150 LB, PN16, PN20
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A890 4A, ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Lug
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium.
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: CL 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
