EN 593 Lug Butterfly Valve, API 609, 4A, 150 LBS, 2-1/2 IN

Name: EN 593 Lug Butterfly Valve, API 609, 4A, 150 LBS, 2-1/2 IN
SKU: 1862202
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : 1862202

As a prominent provider of API 609 butterfly valves in China, we offer high-quality solutions built to meet EN 593 standards. Our 2-1/2 inch (DN65) valves feature a durable ASTM A890 4A construction, ensuring exceptional performance and reliability. With a double eccentric design, RPTFE seat, and a robust 17-4PH stem, these valves are rated for 150 LB pressure. The lug end design facilitates secure installation. Ideal for various industrial applications, our valves deliver both efficiency and long-term durability.

Request a quote

Tags:

Double Offset Butterfly Valves

ASTM A890 4A Butterfly Valve

Lug Butterfly Valve

Detail Information

Double Eccentric Butterfly Valve, Soft Seat, 150 LB, A890 4A Body, Lever Operation.

Valve Description

1862202 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A890 4A, ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8, ASTM B148 C95800.
Nominal Size: 2-1/2 Inch, DN65
Structure: Double Offset, Double Eccentric
Nominal Class: 150 LBS, PN20
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Lever
Seat: RPTFE, PPL
End Connection: Lug
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
