EN 593 Double Eccentric Butterfly Valve, C95800, 6 IN, CL300

Key Specifications / Features

Model no. : BTV-187302026

We are a skilled fabricator of double offset butterfly valves designed to API 609 Category B standards for high-performance applications. This 4-inch valve features a durable body and disc made from aluminum bronze ASTM B148 C95800, offering excellent corrosion resistance in marine and industrial environments. With a Class 300 LB pressure rating, it ensures reliable performance under demanding conditions. The Monel K500 stem adds superior strength and durability. Available in wafer, lug, or flanged end connections, this valve is ideal for precise flow control in corrosive and high-pressure systems.

Detail Information

Valve Description:
187302026 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Structure: Double Eccentric, Double Offset
Nominal Size: 6 Inch, DN150
Nominal Class: Class 300 LB
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Operation: Lever/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
End Connection: Wafer/Lug/Flanged
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service


Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
