EN 593 Butterfly Valves, API 609, ASTM A890 5A, CL 150, 32IN

Key Specifications / Features

Model no. : 1862301

As a leading factory in China specializing in double offset butterfly valves, we offer a 32-inch model that meets API 609 Category B standards. Featuring a Monel K500 stem, RPTFE seat, and soft-seated construction, this valve is made from ASTM A890 5A material and rated Class 150 LB. With wafer ends for easy installation, it is ideal for isolation and regulation in pipelines, especially in applications requiring frequent operation. Its design ensures reliable performance and durability in demanding environments.

Detail Information

Soft Seated Butterfly Valves, API 609 Category B, 32 Inch, 150 LB, Double Offset.

Valve Description

1862301 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Nominal Size: 32 Inch
Nominal Class: Class 150 LB
Seat Type: Soft Seat
Operation: Gear
Seat: RPTFE, PPL
End Connection: Wafer
Body Material: ASTM A890 5A, ASTM B148 C95800, Titanium, ASTM A890 4A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8.
Face to Face: API 609, EN 593
Structure: Double Offset, Double Eccentric
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inches (DN15-DN1200)
Pressure Range: Class 150, 300 LB
Working Temperature: -26°C to +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Seat Type: PTFE, RPTFE, PPL(for higher temperature), RPTF
