EN 593 ASTM A351 CF8 Flanged Butterfly Valves, CL 150, 6 IN

Key Specifications / Features

Model no. : 1862373

We specialize in 6-inch butterfly valves crafted to API 609 Category B and EN 593 standards. Our DN150 valves feature a double offset and double eccentric design, constructed with an ASTM A351 CF8 body and a Monel K500 stem. Rated for CL 150 LB, these valves ensure outstanding performance with a replaceable seat for secure sealing and lower torque. Designed for frequent use, they provide a long service life, supporting up to a million cycles, and offer superior control characteristics for reliable operation.

Detail Information

RPTFE Seated Butterfly Valve, Double Offset, 6 Inch/DN150, Class 150 LB, Double Offset.

Valve Description

1862373 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Body Material: ASTM A351 CF8, ASTM A890 4A, Titanium Alloy, ASTM A351 CF8M, ASTM A216 WCB, ASTM B148 C95800, ASTM A890 5A.
Nominal Size: 6 Inch, DN150
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 5A, ASTM A351 CF8M, ASTM A890 4A, ASTM A351 CF8, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 - 48 Inches (DN15 - DN1200)
Pressure Range: Class 150 - 300 LBS
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Seat Type: PTFE, RPTFE, PPL(for higher temperature), RPTF
