Dual Plate Non-Return Valve, A890 5A, API 6D, 26 IN, 300 LB

Name: Dual Plate Non-Return Valve, A890 5A, API 6D, 26 IN, 300 LB
SKU: 1842052
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : 1842052

Originating from China, we are a prestigious exporter of API 6D Dual Plate Non-Return Valves made from premium Duplex Stainless Steel ASTM A890 5A. Compliant with API 594 standards, our 26-inch valves feature a compact design and ANSI 300 pressure rating, ideal for space-saving installations. The Dual Plate Check Valve offers significant advantages over conventional swing check valves, notably in reduced weight and length, leading to cost savings and optimized space utilization within piping systems. Trust us for high-quality, efficient flow control solutions that meet your exact requirements.

Request a quote

Tags:

ASTM A890 5A Check Valve

API 6D Check Valve

26 Inch Check Valve

Detail Information

API 6D Dual Plate Non-Return Valve, ASTM A890 5A, 26 Inch, Class 300 LB, Wafer/Lug/Flanged Ends.

Check Valve Description
1842052 Dual Plate Non-Return Valve
Design Standard: API 6D, API 594
Structure: Spring Loaded, Dual Plate
Key Features: Compact Design, Independent Spring, Optional Soft and Metal Seat, Unique Slim Plate Design.
Body Material: ASTM A890 5A, ASTM A351 CF8M, ASTM B148 C95800, ASTM A890 4A, ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, Titanium Alloy.
Nominal Size: 26 Inch
Nominal Class: 300 LB
Bore Type: /
End Connection: Wafer, Lug, Double Flanged
Operation: /
Trim Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium Alloy.
Face to Face: API 594
Test and Inspection: API 598

Product Offering

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel, Al-bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
Seat Type: Soft Seat, Metal Seat
End Connections: Wafer, Lug, Flanged(FF, RF, RTJ), Butt Weld(BW), HUB
