Double Offset Titanium Butterfly Valve, API 609, CL 150, 36IN

Key Specifications / Features

Model no. : 1862386

We proudly offer a 36-inch double offset butterfly valve featuring a double eccentric design, compliant with EN 593 and API 609 standards. Constructed with a lightweight titanium body, this valve is rated for Class 150 LB and PN16 applications. Its soft-seated design ensures a tight seal, while the Monel K500 stem provides excellent corrosion resistance. Ideal for demanding environments, our double offset butterfly valve combines durability with high performance, making it an exceptional choice for various industrial applications. Trust us for reliable solutions that meet your needs.

Detail Information

Double Eccentric High-Performance Butterfly Valve, Titanium Body, 36-inch, RPTFE Seat.

Valve Description

1862386 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Nominal Size: 36 Inch, DN900
Nominal Class: Class 150 LB, PN16
Body Material: Titanium, ASTM B148 C95800, ASTM A890 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 4A.
Seat Type: Soft Seat
Operation: Gear
Structure: Double Offset, Double Eccentric
Seat: RPTFE, PPL
End Connection: Double Flanged
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: CL 150-300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
