High-Performance
Butterfly Valves, Titanium Body, 42 IN, DN1200, 300 LB, Double Offset, Lug End.
Valve Description
1862115 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Nominal Size: 42 Inch, DN1050
Nominal Class: Class 300 LB, PN50
Body Material: Titanium, ASTM A216 WCB, ASTM A351 CF8M, ASTM A351 CF8, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800.
Seat Type: Soft Seat
End Connection: Lug
Operation: Gear
Seat: RPTFE, PPL
Face to Face: API 609, EN 593
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Top Mounting: ISO 5211 top mounting is available.
Operation Types: Choose from lever, gear, or pneumatic actuator options.
Bosseal Valve Advantages: Our valves feature zero leakage, low torque, a long working life, low emissions, bi-directional sealing, and fire-safe performance.
