Double Eccentric Butterfly Valves, C95800, 20 Inch, CL300 LB

Name: Double Eccentric Butterfly Valves, C95800, 20 Inch, CL300 LB
SKU: btv-187302033
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : BTV-187302033

We are a specialized factory producing double eccentric butterfly valves engineered for high-performance applications. Designed in compliance with API 609 Category B and BS EN 593 standards, these valves feature a robust ASTM B148 C95800 aluminum bronze body and disc, ensuring excellent corrosion resistance. With a size of 20 inch (DN500) and a pressure rating of Class 300 LB, they are built for demanding industrial and marine environments. Each valve is equipped with a Monel K500 stem for enhanced durability and long service life, delivering reliable sealing and smooth operation.

Request a quote

Tags:

Double Eccentric Butterfly Valve

ASTM B148 C95800 Butterfly Valve

Aluminum bronze Butterfly Valve

Detail Information

Valve Description:
187302033 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Nominal Size: 20 Inch, DN500
Nominal Class: 300 LB
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat Type: Soft Seat
Structure: Double Offset, Double Eccentric
Operation: Lever/Gear
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
End Connection: Wafer/Lug/Flanged
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
