DN50 Floating Ball Valve, 150 LB, 2 IN, WCB, API 608, ISO 17292, RF

Key Specifications / Features

Model no. : 2B1RWCB-P

Discover our top-quality DN50 Floating Ball Valve: 2 Inch, 150 LB, PN20, crafted from ASTM A216 WCB with F316 Trim and Soft Seat. Engineered to API 608, ISO 17292, and API 6D standards, this Two-piece design features Full Bore, RF connection, and Pneumatic Operation for seamless performance.


Detail Information

Floating Ball Valve, ISO 17292, DN50, 150 LB, RF, WCB Body, F316 Trim, Soft Seat, ISO 5211 Mounting pad, Pneumatic Operation

Valve Description:
1812058 Floating Ball Valve 2B1RWCB-P
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 2 Inch, DN50
Nominal class: 150 lb
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Pneumatic Actuator
Body Material: ASTM A216 WCB
Trim Material: ASTM A182 F316, RPTFE/TFM 1600
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Stainless Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: 150 - 300LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator




Nickname*:
E-mail*:
Rate*:
Comments*:

Previous: ASTM A216 WCB Floating Ball Valve, 2 Inch, 150 LB, API608
