Key Specifications / Features

Model no. : CV-20240816-13

As a leading dual plate check valve manufacturer from China, we specialize in high-quality carbon steel valves made from ASTM A216 WCB. Our 6-inch valves meet rigorous standards, including API 594 and API 6D, and feature a robust Class 2500 LB rating. Designed with a compact profile and flanged ends, these valves offer reliable performance and ease of installation in various industrial applications. Trust our expertise and precision engineering to deliver superior dual plate check valves for your needs.


Detail Information

API 594 Dual Plate Check Valve, ASTM A216 WCB, 6 Inch, 2500 LB, Compact Design, Flanged Ends.

Check Valve Specification

1842127 Dual Plate Check Valve
Design Standard: API 594, API 6D
Structure: Spring Loaded, Dual Plate
Key Features: Compact Design, Independent Spring, Optional Soft and Metal Seat, Unique Slim Plate Design.
Nominal Size: 6 Inch
Nominal Class: ANSI Class 2500 LB
Body Material: ASTM A216 WCB, ASTM A351 CF8M, ASTM A352 LCB, Titanium Alloy, ASTM A890 5A, ASTM B148 C95800, ASTM A351 CF8, ASTM A890 4A.
Bore Type: /
End Connection: Wafer, Lug, Double Flanged
Operation: /
Trim Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, CF8M, ASTM A890 4A, 5A, ASTM B148 C95800, Titanium Alloy.
Face to Face: API 594
Test and Inspection: API 598

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 2500 LB
Working Temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Wafer, Lug, Flanged(FF, RF, RTJ), Butt Weld(BW), HUB
Seat Type: Soft Seat, Metal Seat
