Key Specifications / Features
Discover a reliable source for Three-Piece 18 Inch 300 LB DN450 PN50 API 6D ASTM A216 WCB Trunnion Ball Valves with Side Entry, Bolted Bonnet, DIB-1, and RF Flanged Ends – Your trusted Casting Steel Trunnion Ball Valve Supplier.
Detail Information
Trunnion Mounted Ball Valve, API 6D, 18 inch, 300 LB, RF, WCB Casting 3pcs Body, F6A Trim, RPTFE Seat, Gear Operation
Valve Description:
1811049 Trunnion Mounted Ball Valve 18BS3RWCB
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DIB-1
Nominal size: 18 Inch
Nominal class: 300 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: ASTM A182 F6A, RPTFE
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
