Carbon Steel Lug Butterfly Valve, 300 LB, 14 IN, A216 WCB

Key Specifications / Features

Model no. : 1862230

As a premier factory specializing in ASTM A216 WCB butterfly valves, we provide high-quality solutions designed to meet API 609 Category B standards. Our 14-inch valves feature a double eccentric design and are crafted from durable carbon steel with a 300 LB rating. Equipped with a 17-4PH stem and a soft seat, they ensure reliable performance and excellent sealing. The lug ends facilitate easy installation, making these valves ideal for a range of industrial applications requiring robust construction and precise control.

Detail Information

API 609 17-4PH Stem Butterfly Valve, 14 Inch/DN350, 300 LB, Gear Operation.

Valve Description

1862230 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Nominal Size: 16 Inch, DN400
Nominal Class: Class 150 LB, PN16
Body Material: ASTM A216 WCB, ASTM B148 C95800, ASTM A890 5A, ASTM A890 4A, Titanium, ASTM A351 CF8, ASTM A351 CF8M.
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
Structure: Double Offset, Double Eccentric
End Connection: Lug
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2  - 48 Inch (DN15 - DN1200)
Pressure Range: 150  - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
