Key Specifications / Features
The 1841077 Swing Check Valve is a robust choice for industrial applications, designed to BS 1868, API 594, and API 6D standards. This Class 600 LB valve features a 30-inch nominal size and a bolted bonnet for secure operation. Constructed from durable ASTM A216 WCB carbon steel, it offers reliability and longevity. Key features include optional gear operation and a full opening design, complemented by trim materials such as ASTM A182 F6A, F304, F316, F51, F53, and F55. The valve supports both full bore (API 6D) and standard bore (BS 1868, API 594) configurations, with RF flanged end connections for easy installation. Tested to API 598 standards, it ensures high performance and adherence to ASME B16.10 face-to-face dimensions.
Carbon Steel Swing Check Valve, Bolted Bonnet, ASTM A216 WCB, 30 Inch, 600 LB, RF Flanged.
| Valve Descriptions |
1841077 Swing Check Valve |
| Key Features: |
Operation Gear Design Available, Full Opening Design Available, Bolted Bonnet |
| Design Standard: |
BS 1868, API 594, API 6D |
| Nominal Size: |
30 Inch |
| Nominal Class: |
600 LB, PN100 |
| Body Materials: |
ASTM A216 WCB, ASTM A351 CF8, CF8M, ASTM A352 LCB, ASTM A995 4A, 5A, ASTM B148 C95800. |
| Structure: |
Bolted Bonnet |
| Bore Type: |
Full Bore(API 6D) or Standard Bore(BS 1868, API 594) |
| Face to Face: |
ASME B16.10 |
| Test and Inspection: |
API 598 |
| Operation: |
Gear |
| Trim Materials: |
ASTM A182 F6A, F304, F316, F51, F53, F55 |
| End Connection: |
RF Flanged |
Product Portfolio
Body Materials: Stainless Steel, Alloy Steel, Aluminum-Bronze, Carbon Steel.
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -196°C - +450°C
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
End Connection: RF, RTJ, BW
Operation: Not Applicable (Manual or Actuated Available for Special Request)
