Key Specifications / Features
Model no. : BTV-187302007
As a leading butterfly valve manufacturer in China, we offer high-performance aluminum bronze butterfly valves designed to BS EN 593 and API 609 standards. Featuring an ASTM B148 C95800 body and trim with a Monel K500 stem, these 10-inch (DN250) valves deliver excellent corrosion resistance and durability in harsh environments. Rated for Class 150 LB, our valves ensure reliable flow control and sealing performance in marine, oil, gas, and industrial applications. Available in various configurations, they provide dependable service in demanding conditions.
Valve Description:
187302007 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Nominal Size: 10 Inch, DN250
Nominal Class: 150 LB
Seat Type: Soft Seat
End Connection: Wafer/Lug/Flanged
Operation: Lever
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609
Key Features:
Extended service life - Rated for millions of operational cycles.
Low-torque operation - Energy-efficient performance.
Field-replaceable seats - Simplified maintenance and reduced downtime.
Bubble-tight shutoff - Ensures zero leakage in closed position.
Precision flow control - Excellent modulating characteristics.
Bi-directional sealing - Full pressure rating in both flow directions.
Fire-safe design - Optional metal-seated fire-safe configuration.
Marine-grade construction - Aluminum bronze trim for seawater applications.
Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
