BS 5351 Bronze Ball Valve, C95800, 16 IN, 300 LB, Full Bore

Key Specifications / Features

Model no. : BV-187301031

We are a leading aluminum bronze ball valve manufacturer in China, specializing in high-performance valves built to BS 5351 standards. Our 16-inch (DN400) Class 300 LB ball valve is crafted from durable ASTM B148 C95800 aluminum bronze, ensuring excellent corrosion resistance for demanding applications. Designed for full bore flow, it is available with flat face (FF) or raised face (RF) flanged connections and operates at PN20 pressure rating. Our precision-engineered valves provide reliable performance for marine, offshore, and industrial applications. As a trusted manufacturer, we ensure top-quality solutions.

Detail Information

Valve Description:
187301031 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 16 Inch, DN400
Nominal Class: 300 LB
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-Static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: Raised Face, Flat Face Flange
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
