Key Specifications / Features
Explore our premium BS 1868 Swing Check Valves, made in China to meet rigorous standards. These valves feature a robust bolted bonnet design and are constructed from high-quality ASTM A351 CF8M stainless steel, ensuring excellent corrosion resistance and durability. With Trim 12 and compliance with API 594 and API 6D standards, they guarantee reliable performance in Class 300 LB applications. Sized at 4 inches (DN100), these valves are equipped with RF flanged ends for easy installation and maintenance. Ideal for diverse industrial uses, our BS 1868 Swing Check Valves offer superior reliability and efficiency. Choose our products for dependable performance and durability in demanding environments.
Detail Information
BS 1868 Swing Check Valve, Bolted Bonnet, 28 Inch, 150 LB, Flanged, ASTM A351 CF8M, Trim 12.
Descriptions
1841044 Swing Check Valve
Design Standard: BS 1868, API 594, API 6D
Structure: Bolted Bonnet
Sizes: 4 Inch, DN100
Pressure: Class 300 LB
Body Material: ASTM A351 CF8M, CF8, Stainless Steel, ASTM A216 WCB, ASTM B148 C95800, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
End Connection: RF Flanged
Operation: Lever
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available
Face to Face: ASME B16.10
Test and Inspection: API 598
Product Line
Body Materials: Alloy Steel, Carbon Steel, Stainless Steel, Aluminum-bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
Operation: Not Applicable (Manual or actuated available for special request)
