Key Specifications / Features
The 1841068 Swing Check Valve is a robust and reliable choice, designed to meet BS 1868, API 594, and API 6D standards. This Class 600 LB valve features a 10-inch nominal size and a bolted bonnet for secure operation. Constructed with an ASTM A216 WCB body and Trim 8 materials, it ensures durability and high performance. The valve's full opening design and gear operation enhance functionality, while the RF flanged end connection provides easy installation. Tested and inspected to API 598 standards, this valve is ideal for demanding industrial applications.
BS 1868 Swing Check Valve, Class 600 LB, RF Flanged, Bolted Bonnet, 10 Inch, A216 WCB Body with Trim 8
| Valve Descriptions |
1841068 Swing Check Valve |
| Design Standard: |
BS 1868, API 594, API 6D |
| Key Features: |
Bolted Bonnet, Full Opening design available, Operation Gear design Available |
| Body Material: |
ASTM A216 WCB, ASTM A351 CF8M, CF8, ASTM A352 LCB, C95800 Alloy, 4A, 5A. |
| Nominal Size: |
10 Inch, DN250 |
| Nominal Class: |
600 LB |
| Structure: |
Bolted Bonnet |
| Trim Material: |
ASTM A182 F6A, F304, F316, F51, F53, F55 |
| Bore Type: |
Full Standard Bore(BS 1868, API 594) or Bore(API 6D) |
| Face to Face: |
ASME B16.10 |
| Test and Inspection: |
API 598 |
| Operation: |
Gear |
| End Connection: |
RF Flanged |
Product Selection
Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum-Bronze
Normal diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: Class 150 - 2500 LB
Working Temperature: -196°C to +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW)
