Bonnetless Y-pattern Globe Valve, 1-1/2 IN, 2500LB, A182 F11

Key Specifications / Features

Model no. : 1852053

We are a leading manufacturer of Y-Pattern Globe Valves in China, specializing in high-quality valves that meet stringent industry standards, including ASTM A182 F11, ASME B16.34, and API 602. Our 1-1/2 inch valve is rated for 2500 LB pressure, ensuring reliable performance in demanding applications. The bonnetless design provides a compact and space-efficient solution, while the Outside Screw and Yoke (OS&Y) mechanism ensures precise control and durability. Equipped with Butt Weld (BW) ends, the valve offers strong and secure connections for various piping systems. Handwheel operation allows for easy and accurate adjustment of flow. Ideal for applications requiring high-pressure regulation and efficient fluid control, our Y-Pattern Globe Valve combines advanced engineering with robust construction to deliver exceptional performance and reliability.

Detail Information

1-1/2 Inch Y-pattren Globe Valve, ASME B16.34, 1-1/2 Inch, CL 2500 LB, A182 F11 Body, BW Ends.

Valve Description:

1852053 Globe Valve
Design Standard: ASME B16.34, API 602
Body Material: ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A105N, ASTM A182 F91
Nominal Size: 1-1/2 Inch
Nominal Class: Class 2500 LB, PN420
Structure: Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet, Bonnetless
Bore Type: Reduced Bore
Face to Face: MFG'S
Operation: Handwheel
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Applications: Chemical Processing, HVAC Systems, Oil and Gas Industry.

Key Features:

Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service


Product Portfolio
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2-2 Inch (DN15-DN50)
Pressure Range: 800-4500 LB
Operation: Manual or Actuated
Working Temperature: -29°C to +525°C
End Connection: BW/SW/NPT
