Bolted Bonnet Gate Valve, Trim 8, WCB, 2 IN, CL 900, API 600

Key Specifications / Features

Model no. : 1821106

We offer ASTM A216 WCB gate valves designed for durability and performance. Our 2-inch (DN50) valves feature an OS&Y configuration with a flexible wedge for reliable sealing. Rated at Class 900 LB, they come with a bolted bonnet and RTJ flanged ends for secure, leak-proof connections. These valves are available with either handwheel or gear operation, ensuring smooth and precise control. Built to withstand high-pressure conditions, they are ideal for industrial applications that demand long-lasting reliability and efficient flow control. As a leading gate valve manufacturer in China, we are committed to delivering top-quality products to meet your needs.

Detail Information

Bolted Bonnet Gate Valve, ASTM A216 WCB, 2 Inch/DN50, 900 LB, RTJ Flanged, Handwheel/Gear Operation.

Valve Description

1821106 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A351 CF8, ASTM A890 5A, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 2 Inch, DN50
Nominal Class: Class 900 LB, PN150
Bore Type: Standard Bore(API 600)
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
End Connection: RTJ Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
Working Temperature: -29°C - +400°C
Bonnet Types: Bolted Bonnet, Pressure Bonnet, Welded Bonnet, Bellow Seal
