Bolted Bonnet Gate Valve, ASTM B148 C95800, API 600, 10 IN

Key Specifications / Features

Model no. : 1821091

We specialize in bolted bonnet gate valves made from ASTM B148 C95800, known for their exceptional durability and corrosion resistance. These valves are designed for reliable performance in demanding environments, featuring a bolted bonnet that ensures a secure seal and easy maintenance. The ASTM B148 C95800 material, an aluminum bronze alloy, provides excellent strength and resistance to harsh conditions. Ideal for a range of industrial applications, our gate valves offer precise control and long-lasting performance, making them a dependable choice for high-pressure and high-temperature environments. Trust our expertise for superior quality and performance in every valve.

Detail Information

Bolted Bonnet Gate Valve, ASTM B148 C95800, 10 Inch/DN250, 600 LB, OS&Y, RF Flanged.

Valve Description

1821091 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 10 Inch, DN250
Nominal Class: Class 600 LB, PN100
Body Material: ASTM B148 C95800, ASTM A351 CF8M, ASTM A890 5A, ASTM A352 LCB, ASTM A351 CF8, ASTM A216 WCB, ASTM A890 4A.
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: RF Flanged
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature: -29°C - +400°C
