Bolted Bonnet Gate Valve, A890 5A, 26 IN, CL 150, API 600

Key Specifications / Features

Model no. : 1821056

As a leading 26 Inch Gate Valve supplier from China, we offer high-quality 26-inch gate valves made from Duplex Stainless Steel ASTM A890 5A. With a DN650 size and pressure rating of 150 LB, these valves feature an Outside Screw & Yoke (OS&Y) design, a flexible wedge for reliable sealing, and a bolted bonnet for easy maintenance. The RF flanged connection ensures a secure fit, making it ideal for demanding industrial applications. Trust our expertise in delivering durable and efficient valve solutions tailored to your needs.

Detail Information

Bolted Bonnet Gate Valve, ASTM A890 5A, 26 Inch, DN650, 150 LB, OS&Y, RF Flanged.

Valve Description

1821056 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 26 Inch, DN650
Nominal Class: Class 150 LB, PN16
Body Material: ASTM A890 5A, ASTM A352 LCB, ASTM A351 CF8, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature: -29°C - +400°C
