Bolted Bonnet Gate Valve, A352 LCB, 2-1/2 IN, CL 600, API 600

Key Specifications / Features

Model no. : 1821086

We are a trusted supplier of 2-1/2 inch gate valves from China, offering high-quality products made from ASTM A352 LCB material. Designed with an OS&Y structure and flexible wedge for superior sealing, our valves come in DN65 size with a Class 600 LB pressure rating. Featuring a bolted bonnet for durability, RF flanged ends for secure connections, and options for handwheel or gear operation, these valves are ideal for a wide range of industrial applications. Built for reliability and performance, our gate valves ensure efficient flow control in demanding environments.

Detail Information

Bolted Bonnet Gate Valve, ASTM A352 LCB, 2-1/2 Inch, DN65, 600 LB, RF Flanged.

Valve Description

1821086 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A351 CF8, ASTM A890 5A, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
End Connection: RF Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
