Bolted Bonnet Ball Valves, Bronze C95800, C63200 Trim, 26 IN

Key Specifications / Features

Model no. : BV-187301035

We are a leading full bore ball valve manufacturer in China, specializing in high-performance valves built to API 6D, BS 5351, and ASME B16.34 standards. Our 26-inch (DN650) Class 300 LB ball valve is crafted from ASTM B148 C95800 aluminum bronze, ensuring superior corrosion resistance for marine, offshore, and industrial applications. Featuring a bolted bonnet design, it offers enhanced durability, easy maintenance, and reliable sealing. Engineered for high-efficiency flow control, this valve meets stringent industry requirements. As a trusted manufacturer, we deliver durable and high-quality ball valve solutions.

Detail Information

Valve Description:
187301035 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 26 Inch, DN650
Nominal Class: 300 LB
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block & Bleed(DBB), Anti-Static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: RF, FF
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
