Bolted Bonnet Ball Valve, API 6D, ASTM A105N, 32IN, CL1500

Key Specifications / Features

Model no. : 1811171

As a trusted ASTM A105N trunnion ball valve fabricator from China, we produce high-quality valves designed to API 6D and BS 5351 standards. Made from durable carbon steel, our 32-inch (DN800) valves are rated for Class 1500 LB and feature a side entry design for easy access and maintenance. Equipped with a fire-safe design for enhanced safety and RTJ flanged ends for secure connections, these valves are ideal for high-pressure, critical applications in various industries. Built for peRTJormance and reliability, our trunnion ball valves ensure long-lasting service.

Detail Information

32 Inch Trunnion Mounted Ball Valve, 3pcs Body, Carbon Steel, 32 Inch/DN800, 1500 LB, Lever/Gear Operation.

Valve Description

1811171 Trunnion Mounted Ball Valve
Design Standard: API 6D, BS 5351
Nominal size: 32 Inch, DN800
Nominal class: CL 1500 LB, PN250
Body Material: Carbon Steel ASTM A105N or ASTM A350 LF2
Structure: 3pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Bore Type: Full Bore or Reduced Bore
Operation: Lever/Gear
Test and inspection: API 598, API 6D
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to Face: ASME B16.10
End Connection: RTJ Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55, ASTM A105+ENP, ASTM A350 LF2+ENP
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire-Safe Design, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission (Optional), DIB (Optional).

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: 150 - 2500 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C to +150°C
End Connection: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW), Hub
