ASTM B62 C83600 Threaded Bonnet Gate Valve, 1-1/2 IN, CL300

Key Specifications / Features

Model no. : 1876036

We are a reliable supplier of ASTM B62 C83600 gate valves from China, offering products built to MSS SP-80 standards. Our 1-1/2 inch (DN40) gate valves feature a threaded bonnet and are rated for Class 300 LB. Designed with a standard bore for efficient flow, these valves come equipped with non-rising stems for space-saving operation. The handwheel ensures easy and precise control, making them suitable for various industrial applications. Built for durability and performance, our gate valves provide dependable flow regulation.

Detail Information

1-1/2 Inch Bronze Gate Valve, MSS SP-80, DN40, Class 300 LB, Threaded, Union Bonnet.

Valve Description:
1876036 Gate Valve
Design Standard: MSS SP-80
Nominal Size: 1-1/2 Inch, DN40
Nominal Class: Class 300 LB, PN50
Body Material: ASTM B62 C83600
Bore Type: Standard Bore
Structure: Threaded, Union Bonnet
Operation: Handwheel
Face to Face: Manufacturer Standard
Test and Inspection: MSS SP-80
Trim Material: ASTM B62 C83600
End Connection: Threaded ASME B1.20.1

Key Features:
1. Durable renewable solid wedges.
2. Integral seats for better sealing.
3. High-tensile bronze alloy stems for strength.
4. Shell and seat pressure testing per MSS SP-80 standards.
5. Options for rising and non-rising stems.

Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4-3 Inch (DN6 – DN80)
Pressure Range: Class 125 LB, 150 LB, 200 LB, 300 LB
Operation: Handwheel
Working Temperature: -20°C to +150°C
End Connection: NPT Threaded
