ASTM B62 C83600 Rising Stem Gate Valves, 300 LB, 3/8 IN

Key Specifications / Features

Model no. : 1876032

As a leading rising stem gate valve factory in China, we offer high-quality valves designed to MSS SP-80 standards. Our 3/8-inch gate valve features a durable ASTM B62 C83600 bronze body, ensuring excellent corrosion resistance and long-lasting performance. Rated for Class 300 LB, this valve is equipped with a threaded union bonnet for easy maintenance and secure assembly. The handwheel operation allows for precise flow control, while the standard bore design ensures efficient fluid flow. Engineered for reliability, our valves are ideal for a variety of industrial applications.

Detail Information

Rising Stem Bronze Gate Valve, 3/8 Inch, 300 LB, ASTM B62 C83600 Body.

Valve Description:
1876032 Gate Valve
Bore Type: Standard Bore
Design Standard: MSS SP-80
Structure: Threaded, Union Bonnet
Body Material: ASTM B62 C83600
Size Range: 3/8 Inch
Nominal Class: Class 300 LB, PN50
Test and Inspection: MSS SP-80
Trim Material: ASTM B62 C83600
Face to Face: Manufacturer Standard
End Connection: Threaded ASME B1.20.1
Operation: Handwheel

Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing per MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.

Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 IN, 3/8 IN, 1/2 IN, 3/4 IN, 1 IN, 1-1/2 IN, 2 IN, 2-1/2 IN, 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LB, 150 LB, 200 LB, 300 LB
Working Temperature: -20°C to +150°C
End Connection: Threaded
Operation: Handwheel
