ASTM B62 C83600 Gate Valves, Non-Rising Stem, 3/4 IN, CL200

Key Specifications / Features

Model no. : 1876024

As a trusted non-rising stem bronze gate valve supplier from China, we offer top-quality valves that meet MSS SP-80 standards. Crafted with an ASTM B62 C83600 bronze body, this 3/4-inch (DN20) valve is built for reliability and corrosion resistance. Rated for Class 200 LB, it features a threaded bonnet for secure assembly and ease of maintenance. The handwheel operation provides precise control, making it ideal for various industrial applications. Our valves are designed to deliver long-lasting performance and dependable operation in demanding environments.

Detail Information

ASTM B62 C83600 Gate Valves, MSS SP-80, 3/4 Inch, DN20, 200 LB, Threaded Bonnet.

Valve Description:
1876024 Gate Valve
Design Standard: MSS SP-80
Nominal Size: 3/4 Inch, DN20
Nominal Class: Class 200 LB
Body Material: ASTM B62 C83600
Bore Type: Standard Bore
Structure: Threaded, Union Bonnet
Operation: Handwheel
Trim Material: ASTM B62 C83600
End Connection: Threaded ASME B1.20.1
Face to Face: Manufacturer Standard
Test and Inspection: MSS SP-80

Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing under MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.

Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4, 3/8, 1/2, 3/4, 1, 1-1/2, 2, 2-1/2, 3 Inch (DN6 – DN80)
Pressure Range: Class 125, 150, 200, 300 LB
End Connection: Threaded
Working Temperature: -20°C - +150°C
Operation: Handwheel
