ASTM B62 C83600 Bronze Gate Valve, MSS SP-80, 1/4 IN, 125 LB

Key Specifications / Features

Model no. : 1876001

As a leading Bronze Gate Valve Manufacturer in China, we offer valves conforming to MSS SP-80 and made from ASTM B62 C83600 material. Our 1/4 inch, Class 125 LB gate valves feature a threaded or union bonnet and standard bore with a handwheel for easy operation. Designed as multi-turn isolation valves, they ensure full open and close service in pipelines. The valve operates via a threaded stem that presses the gate against two metal seats, typically with hard facing (stellite CoCrW or SS overlay) for durability. Soft seats are also available for specific applications, such as water service.

Detail Information

MSS SP-80 Bronze Gate Valve, 1/4 Inch, CL125 LB, C83600 Body, Standard Bore, Handwheel Operation.

Valve Description

1876001 Gate Valve
Design Standard: MSS SP-80
Structure: Threaded, Union Bonnet
Nominal Size: 1/4 Inch
Nominal Class: Class 125 LB
Bore Type: Standard Bore
End Connection: Threaded ASME B1.20.1
Operation: Handwheel
Body Material: ASTM B62 C83600
Trim Material: ASTM B62 C83600
Face to Face: Manufacturer Standard
Test and Inspection: MSS SP-80

Key Features

1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing in accordance with MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.

Product Range

Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 - 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LB - Class 300 LB
End Connection: Threaded
Working Temperature: -20°C - +150°C
Operation: Handwheel


Drawing for Bronze Gate Valve
