ASTM B148 C95800 Wafer Butterfly Valve, EN 593, 30 IN, CL150

Key Specifications / Features

Model no. : BTV-187302016

We are a leading wafer butterfly valve fabricator in China, specializing in high-performance valves made from aluminium bronze ASTM B148 C95800. Designed to meet BS EN 593 standards, our 30-inch valves are rated for Class 150 LB and are ideal for marine, offshore, and industrial applications. Each valve features a robust Monel K500 stem for superior corrosion resistance and is available with either lever or gear operation for precise flow control. Built for durability and reliability, our valves deliver long-lasting performance in the most demanding service conditions.

Detail Information

Valve Description:
187302016 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Structure: Double Offset, Double Eccentric
Nominal Size: 30 Inch, DN750
Nominal Class: 150 LB
Seat Type: Soft Seat
End Connection: Wafer/Lug/Flanged
Operation: Lever/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609

Key Features:

Extended Service Life: Designed for millions of cycles, ensuring durability for frequent operation.

Low Torque: Smooth and easy operation with reduced torque requirements.

Replaceable Seat: Allows for cost-effective maintenance and long-term performance.

Tight Sealing: Provides reliable, leak-free operation for enhanced safety.

Superior Control: Exceptional control characteristics for precise flow regulation.

Bi-Directional Sealing: Ensures effective sealing under full pressure in both directions.

Fire-Safe Seat: Optional fire-safe seat for added safety in critical applications.

Aluminium Bronze Construction: Ideal for seawater service, offering excellent corrosion resistance.


Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
