Key Specifications / Features
We specialize in exporting high-quality ASTM B148 C95800 Swing Check Valves. Our valves meet the stringent standards of API 594, API 6D, and BS 1868. Featuring a robust bolted bonnet design, these valves are perfect for various industrial applications. With a size of 16 inches (DN400) and a pressure rating of Class 150 LB, they are engineered for reliable performance. The valves come with RF flanged ends, ensuring easy installation and secure connections. Choose our swing check valves for superior durability and performance in demanding environments.
Detail Information
API 594 Swing Check Valve, Bolted Bonnet, 16 Inch/DN400, 150 LB, Flanged, ASTM B148 C95800.
Descriptions
1841029 Swing Check Valve
Design Standard: API 594, BS 1868, API 6D
Structure: Bolted Bonnet
Size: 16 Inch, DN400
Pressure: Class 150 LB
Body Material: ASTM B148 C95800, ASTM A351 CF8M, CF8, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
End Connection: RF Flanged
Operation: Lever
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available
Face to Face: ASME B16.10
Test and Inspection: API 598
Product Line
Body Materials: Alloy Steel, Carbon Steel, Stainless Steel, Aluminum-bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15-DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -196°C to +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
Operation: Not Applicable (Manual or actuated available for special request)
